Optical Power Meter

ST800K Optical power meter with 4 submodel to choose

Key words:

Optical Power Meter

Category:

Optical Power Meter

Hotline:

Optical Power Meter

Product Introduction

ST800K Optical power meter with 4 submodel to choose

4 sub models for your choose

support 2.5mm universial adaptor

6 wavelength

Super safe package

Low price and fast delivery

1pc MOQ

Support OEM

Test range :800~1700nm

850nm, 1300nm, 1310nm, 1490nm, 1550nm, 1625nm 6 wavelengthes

Used for linearity and non-linearity test also can display direct and relative test of the optical power

Being used in the test of LAN, WAN, metropolitan network, CATV net , long-distance fiber net ect.,

Function:

Show dBm or xW

Relative power measurement dB

Support auto off

270, 330, 1K, 2KHz frequency light identification

Low-voltage indication

FC, ST, SC, LC

LCD backlight display

easy-to-operate

Specification list:

Wavelength range	800~1700nm
Detector type	InGaAs
Standard wavelength	850nm, 1300nm, 1310nm, 1490nm, 1550nm, 1625nm
Power testing range	-50~+26 or -70~+3 dBm
Uncertainty	±5%
Resolution	Linearity: 0.1%, Logarithm: 0.01dBm
Specifications as below table:
Adaptors	FC, ST, SC, LC(optional)
Working temperature (℃)	-10~+50
Storage temperature (℃)	-30~+60
Weight	430g (no batteries)
Dimension	200×90×43mm
Battery	4 pcs AA batteries (lithium battery optional)
Batteryworking duration(h)	No less than 150 (according to battery volume)
Auto power-off time	10min
